UACC‑Rack‑42U‑800‑G – Ubiquiti 42U Floor‑Standing Rack Cabinet with Glass Door
Description
Description
The Ubiquiti UACC‑Rack‑42U‑800‑G is a robust, enterprise‑grade 42U floor‑standing rack cabinet designed for professional UniFi network deployments where strength, airflow and accessibility are critical. Constructed from heavy‑duty SPCC steel with a clean white powder‑coated finish, this cabinet provides long‑term durability and a professional appearance.
Supplied fully assembled, the UACC‑Rack‑42U‑800‑G features a lockable tempered glass front door and a solid rear door for secure equipment housing and clear visibility. Integrated cooling fan modules, vertical cable management, removable lockable side panels and adjustable mounting rails ensure efficient airflow, neat cabling and simple maintenance.
Key Features:
- 42U floor‑standing rack cabinet with up to 800 kg static load capacity
- 800 mm depth supporting rack‑mount devices up to 682 mm deep
- Tempered glass front door, lockable and reversible
- Pre‑installed fan modules for active ventilation
- Lockable castors and levelling feet for stability and mobility
- Removable, lockable side panels with vertical cable management
Ideal for:
Enterprise server rooms, IT environments, network closets and large‑scale UniFi installations requiring a heavy‑duty, professional rack solution.
Compatible Products:
Ubiquiti UniFi rack‑mount switches
Ubiquiti Cloud Gateways
Ubiquiti Protect NVR systems
Ubiquiti rack shelves, rails and power management accessories
FAQs:
Is the rack supplied assembled? Yes, it ships fully assembled.
Does it support heavy equipment? Yes, up to 800 kg static and 320 kg rolling load.
Is active cooling included? Yes, integrated fan modules are pre‑installed.
Frequently asked questions3 questions
Is the rack supplied assembled?
Does it support heavy equipment?
Is active cooling included?
Specifications18 specifications · 1 sections
| Overview | |
|---|---|
| Dimensions | Packaging: 740 x 965 x 2,223 mm (29.1 x 38 x 87.5") / Rack with caster: 600 x 800 x 2,050 mm (23.6 x 31.5 x 80.7") / Rack without caster: 600 x 800 x 1,966 mm (23.6 x 31.5 x 77.4") |
| Weight | Packaging: 118.6 kg (261.5 lb) / Rack: 92.4 kg (203.7 lb) |
| Enclosure Material | SPCC steel / Door/side panels: 1.2 mm (0.05") / Main body: 1 mm (0.04") / Posts: 2 mm (0.08") |
| Color | White |
| Treatment | Powder coating |
| Rack Features · U Height | 42U |
| Rack Features · Rack Type | 4 post, enclosed cabinet |
| Rack Features · Mounting Hole Type | Square |
| Rack Features · Adjustable Mounting Depth | Default 607.2 mm (23.9") / Max. 682.2 mm (26.9") / Adjustable pitch 15 mm (0.6") |
| Rack Features · Max. Weight Capacity | Static 800 kg (1764 lb) / Rolling 320 kg (705 lb) |
| Rack Features · Front Door | Tempered glass / Default left-hand outswing, reversible |
| Rack Features · Rear Door | Solid / Default left-hand outswing, reversible |
| Rack Features · Side Panels | (4) Solid, removable and lockable |
| Rack Features · Mounting | Floor stand |
| Rack Features · Fan Module | (2) Pre-installed 120 x 120 x 38 mm AC fan units |
| Rack Features · Cable Entry Opening | (2) Top: 335 x 52.5 mm (13.2 x 2.1") / (2) Bottom: 335 x 52.5 mm (13.2 x 2.1") |
| Rack Features · Security | (1) Front door lock / (1) Rear door lock / (8) Side panel locks / (3) Keys |
| Rack Features · Standard | CE; EIA/ECA-310-E; RoHS |
