US-48-500W Ubiquiti UniFi Switch 48 PoE (500W)
Description
Description
Layer 2, PoE switch with (48) GbE, PoE+ and 24V passive PoE RJ45 ports, (2) 1G SFP ports, and (2) 10G SFP+ ports.
The Switch 48 PoE 500W (US 48 PoE 500W), a fully managed switch with (48) GbE RJ45 ports, (2) 1G SFP ports, and (2) 10G SFP+ ports. Each of the switch's ports can provide either PoE+ or configurable, 24V passive PoE to UniFi access points or other PoE devices.
This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(48) GbE, PoE+ and 24V passive PoE RJ45 ports
(2) 1G SFP ports
(2) 10G SFP+ ports
500W total PoE supply
Managed with the UniFi Network application
Specifications20 specifications · 4 sections
| Overview | |
|---|---|
| Dimensions | 485 x 374.6 x 43.7 mm / (19.09 x 14.75 X 1.72'') |
| Port Layout · 1 GbE RJ45 | 48 (All PoE+) / (1G/100M/10M) |
| Port Layout · 1G SFP | 2 / (1G) |
| Port Layout · 10G SFP+ | 2 / (10G/1G) |
| Max. PoE Output | Up to PoE+ |
| Total PoE Availability | 500W |
| Form Factor | Rack mount (1U) |
| Performance | |
| Access Lists · IPv4 | 128 |
| Access Lists · MAC | 128 |
| Hardware | |
| PoE Ports · PoE+ | 48 |
| Power Method | Universal input, 100–240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 500W |
| Supported Voltage Range | 100–240V AC |
| Management | Ethernet |
| Mount Material | SGCC steel |
| Supported Rack Depth | 400~1200 mm / (15.7-47.2") |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Software | |
| Application Requirements · UniFi Network | Version 6.3.51 and later |
