USW-Flex Ubiquiti UniFi Switch Flex
Description
Description
Layer 2, PoE switch with (5) GbE RJ45 ports, including (4) PoE+ ports and (1) PoE++ input
The Switch Flex (USW Flex) is a fully managed, Layer 2 switch with (5) GbE RJ45 ports, including (4) GbE, PoE+ ports and (1) PoE++ input. Each of the USW Flex's PoE ports can provide up to 25W of power to your UniFi access points and PoE devices. When powered by a PoE++ switch [e.g., USW Pro 48 PoE, USW Pro 24 PoE, US XG 6 PoE, and USW Industrial switches (all sold separately)], the USW Flex can yield a 46W total PoE supply.
The USW Flex sports weatherproof housing and offers a variety of mounting options. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) GbE, PoE++ RJ45 input
(4) GbE, PoE+ RJ45 ports
Up to a 46W total PoE supply*
Weatherproof design
Multiple mounting options
Managed with the UniFi Network application: Version 5.10.3 and later
*When powered with a PoE++ switch or a 60W PoE injector (sold separately).
Specifications25 specifications · 4 sections
| Overview | |
|---|---|
| Dimensions | 122.5 x 107.1 x 28 mm / (4.8 x 4.2 x 1.1") |
| Port Layout · 1 GbE RJ45 | 5 (4 PoE+; 1 PoE++) / (1G/100M/10M) |
| Max. PoE Output | Up to PoE+ |
| Total PoE Availability | PoE++/60W PoE adapter input: 46W / PoE+ input: 20W / PoE input: 8W |
| Form Factor | Compact desktop, wall, pole |
| Performance | |
| Switching Capacity | 10 Gbps |
| Total Non-Blocking Throughput | 5 Gbps |
| Forwarding Rate | 7 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 2,000 |
| Hardware | |
| PoE Ports · PoE+ | 4 |
| PoE Ports · PoE++ | 1 |
| Max. PoE Wattage per Port by PSE · PoE+ | 25W |
| Max. Power Consumption | 5W (Excluding PoE Output) / 51W (Including PoE Output) |
| Power Method | PoE++ |
| Power Input Method | PoE |
| Supported Voltage Range | 50–57V PoE |
| Management | Ethernet |
| Heat Dissipation | 17.1 BTU/hr (Excluding PoE Output) |
| Weight | 230 g (8.1 oz) |
| ESD Protection | Air/contact: ± 16kV |
| Ambient Operating Temperature | 46W PoE output: -40 to 55° C (-40 to 131° F) / 25W PoE output: -40 to 65° C (-40 to 149° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 14502-20-08356 |
| Software | |
| Application Requirements · UniFi Network | Version 5.10.3 and later |
